DESIGN INFORMATION Cooling Capacity 26,167 Watts Cooling Capacity 22,504 kCal/h Model FP - 13 Total Cooling Capacity 22,500 kcal/h - 26.16 kW Water Inlet/Outlet Temperature 35ºC - 30ºC Wet Bulb Temperature 25ºC Water Flow Rate to be Cooled 4.5 m3/h Connection Dimensions Water Inlet: 1 1/4" - Water Outlet: 1 1/4" Dimensions (W) 556mm x (L) 1250mm x (H) 1032mm Loading Weight 115 KG Operating Weight 0.23 Kg Tower Material Used DX51 Galvanized Sheet Fan Motor Information Nominal Power 0.25 kW 1500 RPM (380 volts) Power Consumption 0.19 kW Protection Class Class F Motor Drive System Specifications: Belt Pulley Connection, Sound Level: Max 80 Decibels from 1 Meter, Electrical Supply: 380 V – 3 Phase – 50 Hz, Fan Information: Fan Type: Axial, Fan Blades: 4 Steel Blades, Fan Hub: Steel Body, Number of Fans: 1, Fan Diameter: Ø 450mm, Air Flow Rate: 2.227 m3/h, Hydraulic System: Water Distribution, Hot Water Pool Interior, Removable Nozzle, Daisy Model Nozzle, Sprinkler Filling Material: Curler Filling Eliminator: PP Droplet Catcher, Air Velocity in Filling: 2.75 m/s, Evaporation Amount: 0.0343 m3/h, Drag Loss: 0.007%, Water Head: 16.00 t/m2.h, Total Pressure Loss: 3.5 mmss. Tower Accessories: Fan Guard: Aerodynamically designed, pitched, removable fan guard, Tensioners: Cast Rope Tensioner, Motor Cover: Rain guard, fully enclosed cover. WARRANTY PERIOD Our products have CE and ISO certificates and are guaranteed for 1 year against manufacturing defects.
