FP-37 Cross-Flow Axial Fan Water Cooling Tower

SPECIFICATIONS Cooling Capacity 69,186 Watts Cooling Capacity 59,500 kCal/h Model FP - 37 Total Cooling Capacity 595,000 kcal/h - 691.86 kW Water Inlet/Outlet Temperature 35ºC - 30ºC Wet Bulb Temperature 25ºC Water Flow Rate to be Cooled 119 m3/h Connection Dimensions Water inlet: 6" Water outlet: 6" Dimensions (W) 2500mm x (L) 2450mm x (H) 2430mm Loading Weight 1160 KG Operating Weight 3.16 Kg Tower Material Used DX51 Galvanized Sheet Fan Motor Information Nominal Power 5.5 kW 1500 rpm (380 Volts) Power Consumption 4.10 kW Protection Class Class F Motor Drive System Belt Pulley Connection Noise Level Max 80 Decibels from 1 Meter Electrical Supply 380 V – 3 Phase – 50 Hz Fan Information Fan Type Axial Fan Blades 4 Steel Blades Fan Hub Steel Body Number of Fans 1 Fan Diameter Ø 1200 mm Air Flow Rate 58.905 m3/h Hydraulic System Water Distribution Hot Water Pool Interior Removable Nozzle Daisy Model Nozzle Sprinkler Filling Material Curler Filling Eliminator PP Droplet Catcher Air Velocity in Filling 2.75 m/s Evaporation Amount 0.9104 m3/h Drag Loss 0.007% Water Head 50.10 t/m2.h Total Pressure Loss 4.2 mmss Tower Accessories Fan Guard Aerodynamically designed pitched removable type fan guard Tensioners Cast Rope Tensioner Motor Cover Rain guard, fully enclosed Hat Warranty Period: Our products have CE and ISO certificates and are guaranteed against manufacturing defects for 1 year.
